SMIC-ZXQ-5 Automatyczna praska do przygotowywania próbek
Application The sample inlaying machine can inlay improper samples in shape or size to meet the following sampling steps, to obtain required inspection surface, or to protect edges or surface defects caused in the course of sample preparation. In modern metallographic labs, semi-automatic or automatic grinding/polishing machines have a certain requirement in sample size, so the samples must be inlayed. The sample in...
Technical Parameters
1. Specification of Die: φ25mmφ30mmφ40mmφ50mm
2. Power Supply: 220V 50HZ
3. Max. Power Consumption: 1600W
4. Setting of System Pressure: 0~2MPa (setting of sampling pressure: 0~72MPa)
5. Setting of Temperature: 0~300℃
6. Setting of Heat Holding Time: 0~99 min. 99 sec.
7. Dimensions: 615mm×510mm×500mm
8. Weight: 110kg
9. Type of Cooling: water-cooled
